DOOM

Batocera is shipped with the SHAREWARE version of Doom. So you can play Episode 1 of this insane 3rd person shooter from 1993.

When adding .wad files, make sure you put the filenames in lowercase. Uppercase .WAD won't work.

On some ARM platforms floor and ceilings got some disturbtive graphics output. Disabling it completely gets rid of the effect. This screenshot illustrates the problem at full effect! This is due to some fix for texture “vibrations” (not exactly the same issue as the wiggle but triggered with the same option) the fix was backported from prboom-plus but it seems it's causing trouble in some platforms.

So how to fix? Start PRBOOM → Options → General → 3rd page Whiggle fix → No

Annother method? Yes, navigate to /userdata/saves/prboom/[DOOM-EPISODE]/prboom.cfg and search Video Section for r_wiggle_fix and disable it.

## Video settings
#screenblocks                  0
#usegamma                      0
#uncapped_framerate            3
#filter_wall                   1
#filter_floor                  1
#filter_sprite                 1
#filter_z                      1
#filter_patch                  1
#filter_threshold          49152
#sprite_edges                  0
#patch_edges                   0
#render_stretchsky             1
r_wiggle_fix                  0

General: IWAD = Internal Where's All the Data and PWAD = Patch Where's All the Data. So in general IWADs are standalone files and can be started aloneside. Some examples can be (e.g.)

• DOOM Shareware
• DOOM Full Version
• DOOM Ultimate DOOM
• DOOM2 Hell on Earth
• DOOM2 BFG EDITION
• DOOM BFG EDTION
• FREEDOOM Phase 1 (DOOM Ultimate free plot)
• FREEDOMM Phase 2 (DOOM2 free plot)
• DOOM2 - Plutonia Experiment
• DOOM2 - TNT Evilution

Corresponding MD5 checksums of popular WADs:

• Doom I - v1.9

DOOM.WAD cd63c5ddff1bf8ce844237f580e9cf3

• Doom 1 - Episode 5 SIGIL (v1.21)

SIGIL_v1_21.WAD 743d6323cb2b9be24c258ff0fc350883

• Doom II - Hell on Earth v1.9

DOOM2.WAD 25e1459ca71d321525f84628f45ca8cd

• Final Doom - Evilution v1.9

TNT.WAD 4e158d9953c79ccf97bd0663244cc6b6

• Final Doom - The Plutonia Experiment v1.9

PLUTONIA.WAD 75c8cf89566741fa9d22447604053bd7

• Ultimate Doom

DOOMU.WAD c4fe9fd920207691a9f493668e0a2083

SIGIL is the 5th Episode for ULTIMATE DOOM. It was created by the creator of DOOM - John Romero and can be downloaded for free right here.

How to use?

Place the downloaded WAD to your prboom directory in roms. Now edit /userdata/saves/prboom/[DOOM1-EPISODE]/prboom.cfg and set the WAD next to be loaded to the main WAD in Files Section. I've only tested for ULTIMATE DOOM and it worked like a charme.

## Files
wadfile_1                 "SIGIL_v1_2.wad"
#wadfile_2                 ""
#wadfile_3                 ""
#wadfile_4                 ""
#wadfile_5                 ""
#wadfile_6                 ""
#wadfile_7                 ""
#wadfile_8                 ""
#dehfile_1                 ""
#dehfile_2                 ""

The Lost Episodes of Doom is a collection of three eight-level episodes for Doom by Christen Klie and Bob Carter. It takes place on the Jovian moons Callisto and Io, and on Jupiter itself. It was a commercial product.

Extract the two WAD files and then edit /userdata/saves/prboom/[DOOM1-EPISODE]/prboom.cfg and set the WAD next to be loaded to the main WAD in Files Section.

## Files
wadfile_1                 "JPTR_V40.WAD"
wadfile_2                 "Jptr_fix.wad"
#wadfile_3                 ""
#wadfile_4                 ""
#wadfile_5                 ""
#wadfile_6                 ""
#wadfile_7                 ""
#wadfile_8                 ""
#dehfile_1                 ""
#dehfile_2                 ""

No Rest for the Living was developed by Nerve Software for the release of Doom 2 on the XBLA. The episode consists of nine levels in all, eight standard levels and a single secret level, as a homage to the similarly structured nine-map episodes in the original Doom, particularly Knee-Deep in the Dead.

Extract the WAD file and then edit /userdata/saves/prboom/[DOOM2-EPISODE]/prboom.cfg and set the WAD next to be loaded to the main WAD in Files Section.

## Files
wadfile_1                 "NERVE.WAD"
#wadfile_2                 ""
#wadfile_3                 ""
#wadfile_4                 ""
#wadfile_5                 ""
#wadfile_6                 ""
#wadfile_7                 ""
#wadfile_8                 ""
#dehfile_1                 ""
#dehfile_2                 ""

The above methods gots the disadvantage that you “lose” your original gameset. That means for DOOM-Sigil that you will the new launching screen ever and ever again. To get rid of this you can copy the main WAD and rename one to DOOM - Ultimate DOOM.wad and the other to DOOM - Sigil of Baphomet.wad now you edit /userdata/saves/prboom/DOOM - Sigil of Baphomet.wad/prboom.cfg and set it up like written above.

Now you edit gamedata and hide the added PWAD files (Sigil.wad), you now have a clean list.

If you intend to use Doom mods, you need to create subdirectories for each mod you want to enable, and keep a copy of the original doom.wad or doom2.wad in the mod subdirectory, with the corresponding .wad for the mod. Generally when you launch a mod, the Doom Logo has been modified by the modder and you can tell what is the base wad.

For example : Simpsons Ultimate Doom

In the screenshot below, you can see how you can make it work. The original .wad files have been renamed .wadd so that PrBoom doesn't load and give them priority over the other wads.
