Namco System 246/256

The Namco System 246/256 is an arcade developed by Sony / Namco. It was released in 2000.

This system scrapes metadata for the “namco, sega, arcade” group(s) and loads the namco2x6 set from the currently selected theme, if available.

Quick reference

  • Emulator: play
  • Folder: /userdata/roms/namco2x6
  • Accepted ROM formats: .zip

BIOS

No Namco System 246/256 emulator in Batocera needs a BIOS file to run.

ROMs

Place your Namco System 246/256 ROMs in /userdata/roms/namco2x6.

The Play! emulator provides `work in progress` support for Namco 246 & 256 systems.

Currently you will need a high performance system to be able to emulate supported games.

We recommend using the OpenGL API for now.

This rom directory should include a zip file based on the arcade id and a supporting folder with associated .chd file.

i.e. Tekken 4 -

tekken4.zip
|
tekken4
|
---tef1dvd0.chd

Emulators

play

play configuration

Standardized features available to all cores of this emulator: namco2x6.videomode, namco2x6.padtokeyboard, namco2x6.powermode, namco2x6.tdp, namco2x6.videomode, namco2x6.bezel, namco2x6.bezel_stretch, namco2x6.hud, namco2x6.hud_corner, namco2x6.bezel.tattoo, namco2x6.bezel.tattoo_corner, namco2x6.bezel.tattoo_file, namco2x6.bezel.resize_tattoo, namco2x6.use_wheels, namco2x6.wheel_rotation, namco2x6.wheel_deadzone, namco2x6.wheel_midzone

ES setting name batocera.conf_key Description ⇒ ES option key_value
Settings that apply to all cores of this emulator
GRAPHICS API namco2x6.play_api Choose which graphics API library to use.
⇒ OpenGL (Default) 0, Vulkan 1.
OPENGL RENDERING RESOLUTION namco2x6.play_scale Enhancement. Increase the rendering resolution. Makes 3D objects clearer.
⇒ 1x (~480) 1, 2x (~960) 2, 4x (~1920p) 4, 8x (~4320p / 8k) 8, 16x (~7680p / 16k) 16.
PRESENTATION MODE namco2x6.play_mode
⇒ Fill Screen 0, Fit Screen 1, Original Size 2.
ENABLE WIDESCREEN namco2x6.play_widescreen Enable widescreen support.
⇒ Disabled false, Enabled true.
VSYNC namco2x6.play_vsync Fix screen tearing.
⇒ Disabled false, Enabled true.
SMOOTH GAMES (BILINEAR FILTERING) namco2x6.play_filter Only applicable when using OpenGL.
⇒ Disabled false, Enabled true.
LANGUAGE namco2x6.play_language Change the game's language.
⇒ Japanese 0, English 1, French 2, Spanish 3, German 4, Italian 5, Dutch 6, Portuguese 7, Russian 8, Korean 9, Traditional Chinese 10, Simplified Chinese 11.

Controls

Here are the default Namco System 246/256's controls shown on a Batocera RetroPad:

Troubleshooting

Further troubleshooting

For further troubleshooting, refer to the generic support pages.
